Data Sheet
Test Fixtures
Fixture Description
TDSUSBF Test fixture for use with Opt. USB
Probe Calibration/Power
Deskew Fixture
Order 067-1686-xx
TF-GBE-ATP 1000/100/10BASE-T Advanced Ethernet Test Package,
includes test fixture, RJ-45 interconnect cable, and
1000BASE-T jitter test channel cable
TF-GBE-BTP 1000/100/10BASE-T Basic Ethernet Test Package,
includes test fixture and RJ-45 interconnect cable
ATM-1 Advanced CAN and LIN triggering module
Adapters
Adapter Description
P6701B* 6 Optical/Electrical converter (Multi Mode)
P6703B* 6 Optical/Electrical converter (Single Mode)
* 6 Probe requires TPA-BNC adapter.
Optional Software
Software Description
PDU-R Prodigy RS-232/UART decode application
PDI-R Prodigy I 2 C decode application
PDS-R Prodigy SPI decode application
PDF-R Prodigy FlexRay decode application
SIGEXPTE NI LabVIEW SignalExpress™ Tektronix Edition
Software (Full Version)
Instrument Upgrades
To upgrade your DPO7000 Series oscilloscope, order DPO7UP with option as
noted:
Option Description
To upgrade record length:
RL02 From Standard Configuration to Opt. 2RL Configuration
RL05 From Standard Configuration to Opt. 5RL Configuration
RL010* 5 On DPO7254 or DPO7354 from Standard Configuration
to Opt. 10RL Configuration
RL25 From Opt. 2RL Configuration to Opt. 5RL Configuration
RL210* 5 On DPO7254 or DPO7354 from Opt. 2RL Configuration
to Opt. 10RL Configuration
RL510* 5 On DPO7254 or DPO7354 from Opt. 5RL Configuration
to Opt. 10RL Configuration
To upgrade DPO7000 Series with:
ASM* 12 Advanced Search and Mark
CP2* 7 TDSCPM2 ANSI/ITU Telecom pulse compliance testing
software
D-PHY* 5, 9 MIPI ® D-PHY Essentials
DDRA* 9 Opt. DDRA
DJAM Opt. DJA
DJEM* 12 DPOJET Jitter and Eye Diagram Analysis – Essentials
DVI* 8 Opt. DVI
ET3* 3 Opt. ET3
J2 TDSDDM2 disk drive analysis software
LSA Opt. LSA
LT* 12 Waveform Limit Test
MTM Opt. MTM
PTM* 5 To upgrade DPO7254 or DPO7354 with Opt. PTM
PWR Opt. PWR
RTE* 5 Opt. RTE or TDSRT eye software
SVEM Opt. SVE
SVM* 10 Opt. SVM
SVP* 10 Opt. SVP
SVT* 10 Opt. SVT
USB* 4 Opt. USB
UWB* 5 Opt. UWB
UWBE* 5 Opt. UWBE
* 3 Requires Ethernet Test Fixture TF-GBE-ATP or TF-GBE-BTP.
* 4 Requires TDSUSBF (USB Test Fixture). Greater than 2 GHz bandwidth required for high-speed USB.
* 5 DPO7254 or DPO7354 only.
* 7 Requires Opt. MTM.
* 8 DPO7354 only.
* 9 Requires Opt. DJA.
* 10 Requires Opt. SVE or SVEM.
* 12 Included as standard feature on units with serial number above B070000 and C010100.
Product(s) are manufactured in ISO registered facilities.
