Digital Phosphor Oscilloscopes
DPO7000 Series Data Sheet
Features & Benefits
3.5 GHz Bandwidth Model for Serial and Digital Applications
2.5 GHz, 1 GHz, and 500 MHz Bandwidth Models for All Applications
Up to 40 GS/s Real-time Sample Rate on One Channel and up to
10 GS/s on All Four Channels
Up to 500 Megasamples Record Length with MultiView Zoom™ Feature
for Quick Navigation
>250,000 wfms/s Maximum Waveform Capture Rate
Up to 310,000 Waveforms per Second with FastFrame™ Segmented
Memory Acquisition Mode
User-selectable Bandwidth Limit Filters for Better Low-frequency
Measurement Accuracy
MyScope ® Custom Windows and Right Mouse Click Menus for
Exceptional Efficiency
Event Search and Mark to Find Specific Events in the Entire Waveform
Pinpoint ® Triggering provides the Most Flexible and Highest
Performance Triggering, with Over 1400 Combinations to Address
Virtually Any Triggering Situation.
12.1” XGA Display with Touch Screen
Communications Mask Testing
Clock Recovery from Serial Data Streams
64-bit NRZ Serial Pattern Trigger for Isolation of Pattern-dependent
Effects up to 1.25 Gb/s
Low-speed Serial Protocol Triggering and Decode (I 2 C, SPI, RS-232,
CAN, LIN, and FlexRay)
Technology-specific Software Solutions provide Built-in Domain
Expertise for MIPI
® D-PHY, Ethernet, USB 2.0 Compliance Testing, Jitter,
Timing, Eye Diagram, Power, DDR Memory Bus Analysis, CAN, LIN, and
FlexRay Network Design
OpenChoice ® Software with Microsoft Windows XP OS enables Built-in
Networking and Extended Analysis
Applications
Signal Integrity, Jitter, and Timing Analysis
Verification, Debug, and Characterization of Sophisticated Designs
Debugging and Compliance Testing of Serial Data Streams for Telecom
and Datacom Industry Standards
Low-speed Serial Bus Design (I 2 C, SPI, RS-232, CAN, LIN, and
FlexRay)
Investigation of Transient Phenomena
Power Measurements and Analysis
Spectral Analysis
