Data Sheet

Environmental

Characteristic

Description

Temperature

Operating

0 °C to +50 °C, excluding CD-R/W drive; +10 °C to

+45 °C, including CD-R/W drive

Nonoperating

–40 °C to +71 °C

Humidity

Operating

5% to 95% relative humidity (RH) with a maximum

wet bulb temperature of +29 °C at or below +50 °C,

noncondensing. Upper limit derated to 45% RH above

+30 °C up to +50 °C

Nonoperating

5% to 95% relative humidity (RH) with a maximum

wet bulb temperature of +29 °C at or below +60 °C,

noncondensing. Upper limit derated to 45% RH above

+30 °C up to +50 °C

Altitude

Operating

10,000 ft. (3,048 m)

Nonoperating

40,000 ft. (12,190 m)

Random Vibration

Operating

0.000125 G

2

/Hz from 5 to 350 Hz, –3 dB/octave from

350 to 500 Hz, 0.0000876 G

2

/Hz at 500 Hz. Overall

level of 0.27 G

RMS

Nonoperating

0.0175 G

2

/Hz from 5 to 100 Hz, –3 dB/octave from

100 to 200 Hz, 0.00875 G

2

/Hz from 200 to 350 Hz,

–3 dB/octave from 350 to 500 Hz, 0.006132 G

2

/Hz at

500 Hz. Overall level of 2.28 G

RMS

Regulatory

Electromagnetic

Compatibility

93/68/EEC; EN61326:1997 +A1 1998+A2:2000

Certifications

UL 3111-1, CSA1010.1, ISO11469, EN61010-1, IEC

61010-1

Ordering Information

DPO7000 Series

Product

Description

DPO7054

500 MHz Digital Phosphor Oscilloscope

DPO7104

1 GHz Digital Phosphor Oscilloscope

DPO7254

2.5 GHz Digital Phosphor Oscilloscope

DPO7354

3.5 GHz Digital Phosphor Oscilloscope for Serial and

Digital applications

All Models Include:

Accessory pouch, front cover, mouse, (4) P6139B 500 MHz,

10x passive probes, quick-start user manual (071-173x-xx), DPO7000 Series

product software media, DPO7000 Series operating system restoration media,

optional applications software media, performance verification procedure PDF file,

GPIB programmer's reference (on product software media), calibration certificate

documenting NIST traceability, Z 540-1 compliance and ISO9001, power cord,

one-year warranty.

Note: User to specify quick-start user manual language, and power plug when

ordering.

(Probes and accessories are not included in the oscilloscope warranty. Refer to the

data sheet for each probe for its unique warranty and calibration terms.)

Options

Instrument Options

Option

Description

Record Length Options

Opt. 2RL

125 MS max, 25 MS/Ch

Opt. 5RL

250 MS max, 50 MS/Ch

Option

Description

DPO7254/DPO7354 Only

Opt. 10RL*

5

500 MS max, 125 MS/Ch

DPO7104 Only

Opt. 2SR*

2

Double the maximum real-time sample rate to 40 GS/s

(1 channel), 20 GS/s (2 channels), 10 GS/s (3 or

4 channels)

Software Options

Opt. DDRA*

9

DDR Memory Bus Analysis

Opt. DJA

DPOJET Jitter and Eye Diagram Analysis – Advanced

Opt. ET3*

3

TDSET3 Ethernet Compliance Test Software

Opt. HEAC*

11

HEAC Compliance Test Software

Opt. LSA

Low-speed Serial Analysis includes CAN Trigger, and

CAN/LIN Decode and Analysis

Opt. MTM

Mask Testing for Serial Communication Standards (up

to 1.5 Gb/s). Includes hardware clock recovery on

DPO7254/DPO7354

Opt. PWR

DPOPWR Power Measurement and Analysis Software

Opt. SVE

SignalVu™ Essentials – Vector Signal Analysis

Software

Opt. SVM*

10

General-purpose Modulation Analysis. Requires Opt.

SVE

Opt. SVP*

10

Advanced Signal Analysis (including pulse

measurements). Requires Opt. SVE

Opt. SVT*

10

Frequency and Phase Settling Time Measurements.

Requires Opt. SVE

Opt. TEKEXP

TekExpress Automation Framework

Opt. USB*

4

USB 2.0 Compliance Test Software

DPO7254/DPO7354 Only

Opt. D-PHY*

5, 9

MIPI

®

D-PHY Essentials – Characterization and

Compliance test solution

Opt. PTM*

5

8b/10b protocol decoding and NRZ serial pattern

triggering. Includes hardware clock recovery up to

1.25 Gb/s and pattern lock triggering

Opt. RTE*

5

RT-Eye

®

Serial data compliance and analysis software

Opt. UWB*

5

Ultra-Wideband Spectral Analysis Software. Includes

WiMedia compliance tests

Opt. UWBE*

5

Ultra-Wideband Spectral Analysis Essentials. Does not

include WiMedia compliance tests

DPO7354 Only

Opt. DVI*

8

Digital Visual Interface compliance test software

XGBT*

8, 11

10GBASE-T Automation Solution

Bundle Options

Opt. PS1

Power Bundle option includes TPA-BNC adapter, probe

calibration and deskew fixture 067-1686-xx, P5205,

TCP0030, and Opt. PWR

Floating licenses offer an alternative method to manage your Tektronix asset.

Floating licenses allow license-key enabled options to be easily moved among

all your DPO/DSA70000B, MSO70000, and DPO7000 Tektronix oscilloscopes.

Floating licenses are available for many license-key enabled options. To order a

floating version of an option license add “DPOFL-“ prefix to the option name. (e.g.

DPOFL-ET3)

Check www.tek.com/products/oscilloscopes/floatinglicenses for additional

information about floating license options.

*

2

DPO7104 only.

*

3

Requires Ethernet Test Fixture TF-GBE-ATP or TF-GBE-BTP.

*

4

Requires TDSUSBF (USB Test Fixture). Greater than 2 GHz bandwidth required for high-speed USB.

*

5

DPO7254 or DPO7354 only.

*

8

DPO7354 only.

*

9

Requires Opt. DJA.

*

10

Requires Opt. SVE or SVEM.

*

11

Requires Opt. TEKEXP.

16
