Data Sheet
Time Base System
Characteristic DPO7054 DPO7104 DPO7254 / DPO7354
Time Base Range 50 ps/div to 1000 s/div 50 ps/div to 1000 s/div 25 ps/div to 1000 s/div
with Opt. 2SR
—
25 ps/div to 1000 s/div
—
Time Resolution (in ET/IT mode) 500 fs 500 fs 250 fs
with Opt. 2SR — 250 fs —
Time Base Delay Time Range 5 ns to 250 s
Channel-to-Channel Deskew Range ±75 ns
Delta Time Measurement Accuracy ((0.06 / sample rate) + (2.5 ppm × Reading)) RMS
Trigger Jitter (RMS) 1.5 ps
RMS
(typical) with enhanced triggering OFF
<100 fs
RMS
with enhanced triggering ON
Jitter Noise Floor <1 ps
RMS
(<2 ps peak) for record duration <10 μs (typical)
<2.5 ps
RMS
for record duration <30 ms
<65 parts/trillion for record durations <10 s
Time Base Accuracy ±2.5 ppm + Aging <1 ppm per year
Acquisition System
Characteristic DPO7054 DPO7104 DPO7254 / DPO7354
Real-time Sample Rates
1 Channel (Max) 20 GS/s 20 GS/s 40 GS/s
with Opt. 2SR
—
40 GS/s
—
2 Channels (Max) 10 GS/s 10 GS/s 20 GS/s
with Opt. 2SR
—
20 GS/s
—
3-4 Channels (Max) 5 GS/s 5 GS/s 10 GS/s
with Opt. 2SR
—
10 GS/s
—
Equivalent Time Sample Rate (Max) 4 TS/s (for repetitive signals)
Maximum Record Length per Channel
Standard Configuration 50 M (1-CH), 25 M (2-CH), 12.5 M (4-CH)
Record Length Opt. 2RL 125 M (1-CH), 50 M (2-CH), 25 M (4-CH)
Record Length Opt. 5RL 250 M (1-CH), 125 M (2-CH), 50 M (4-CH)
Record Length Opt. 10RL — — 500 M (1-CH)
250 M (2-CH)
125 M (4-CH)
Maximum Duration at Highest Real-time Resolution (1-CH)
Characteristic DPO7054 DPO7104 DPO7254 / DPO7354
Resolution 50 ps (20 GS/s) 50 ps (20 GS/s) 25 ps (40 GS/s)
with Opt. 2SR — 25 ps (40 GS/s) —
Max Duration with Standard Record
Length and Sample Rate
2 ms 2 ms 1 ms
with Opt. 2SR
—
1 ms
—
Max Duration with Opt. 2RL 4 ms 4 ms 2 ms
with Opt. 2SR
—
2 ms
—
Max Duration with Opt. 5RL 10 ms 10 ms 5 ms
with Opt. 2SR
— 5 ms —
Max Duration with Opt. 10RL
— —
10 ms
