Version 07.00, August 2013

Rohde & Schwarz R&S

®

ZNB Vector Network Analyzer

25

General data

Temperature loading

in line with IEC 60068-2-1 and

IEC 60068-2-2

operating temperature range

+5 °C to +40 °C

storage temperature range

–20 °C to +60 °C

Damp heat

+40 °C at 85 % rel. humidity,

in line with IEC 60068-2-30

Altitude

operating environment

max. 2000 m

storage environment

max. 4500 m

Mechanical resistance

vibration, sinusoidal

5 Hz to 55 Hz, 0.15 mm amplitude

constant,

55 Hz to 150 Hz, 0.5 g constant,

in line with IEC 60068-2-6

vibration, random

10 Hz to 300 Hz, acceleration 1.2 g (RMS)

in line with IEC 60068-2-64

shock

40 g shock spectrum,

in line with MIL-STD-810E method

no. 516.4 procedure I

Calibration interval

1 year

EMC

RF emission

in line with CISPR 11/EN 55011 group 1

class A (for a shielded test setup);

instrument complies with the emission

requirements stipulated by EN 55011 and

EN 61326-1 class A; this means that the

instrument is suitable for use in industrial

environments

immunity

in line with EMC Directive 2004/108/EC

including: IEC/EN 61326-1 (immunity test

requirement for industrial environment,

EN 61326 table 2), IEC/EN 61326-2-1,

IEC/EN 61000-3-2, IEC/EN 61000-3-3

Safety

in line with IEC 61010-1, EN 61010-1 and

UL 61010-1

Power supply

100 V to 240 V at

50 Hz to 60 Hz and 400 Hz,

max. 5.5 A to 2.3 A respectively

Power consumption

R&S

®

ZNB4 and R&S

®

ZNB8,

with two ports

max. 450 W, typ. 120 W

R&S

®

ZNB4 and R&S

®

ZNB8,

with four ports

max. 450 W, typ. 170 W

R&S

®

ZNB20 and R&S

®

ZNB40,

with two ports

max. 450 W, typ. 130 W

R&S

®

ZNB20 with four ports

max. 450 W, typ. 215 W

Test mark

VDE, GS,

C

CSA

US

, CE conformity mark

Dimensions (W × H × D)

461.1 mm × 239.9 mm × 351.0 mm

(18.2 in × 9.6 in × 13.9 in)

Weight

R&S

®

ZNB4, R&S

®

ZNB8, R&S

®

ZNB20 and

R&S

®

ZNB40,

with two ports

14 kg (30.9 lb)

R&S

®

ZNB4, R&S

®

ZNB8 and R&S

®

ZNB20,

with four ports

16 kg (35.3 lb)

Shipping weight

R&S

®

ZNB4, R&S

®

ZNB8, R&S

®

ZNB20 and

R&S

®

ZNB40,

with two ports

19 kg (41.9 lb)

R&S

®

ZNB4, R&S

®

ZNB8 and R&S

®

ZNB20,

with four ports

21 kg (46.3 lb)
