Fluke Networks OptiView™ Integrated Network Analyzer
Trace SwitchRoute
The OptiView analyzers’ Trace SwitchRoute feature allows you to see the
exact path two devices use to communicate through your switch fabric.
The Trace SwitchRoute begins its discovery from the specified Source
Device and traces the path to the specified Target Device. For each
switch in the path, the displayed results include the name, address,
slot and port number together with link speed and VLAN information.
Highlighting any device in the Trace SwitchRoute name column and
selecting Host Detail will allow you to view information on that
device’s network configuration.
