32
Infiniium 90000 Series ordering information
Note: The DSA/DSO91304A uses DSP enhancement software to achieve 13 GHz bandwidth. It also adds a valuable DSP
noise reduction and bandwidth control feature to reduce noise at bandwidths of 10, 8, 6, 4, 2, and 1 GHz. The non-DSP
enhanced bandwidth of the
DSA/DSO91304A is 12 GHz. DSA Series comes with standard 50 Mpts memory, high speed serial data analyzer (Option
003/E2688A), EZJIT plus jitter analysis software (Option 004/N5400A)
Standard accessories
• USB optical mouse
• USB keyboard
• User’s quick-start guide
• Detachable accessory pouch
• Power cord
• Stylus pen
• High-performance calibration cable (not included in DSA/DSO90254A)
• E2655B probe deskew and performance verification kit
• Two 54855-67604 BNC-compatible to precision 3.5 mm (f) adapters (not included in
DSA/DSO90254A)
• One-year warranty
Note: No probes are included with the DSA/DSO90000A Series oscilloscopes. The InfiniiMax Series probes or any other
probes must be purchased separately.
Additional options and accessories
DSO90000A-1CM Rack Mount Kit
DSO90000A-A61 ANSI Z540 Compliant Calibration
DSO90000A-801 Removable Solid State Drive
N2892A
(requires Option 801)
Additional removable solid state drive for
90000 Series with Windows 7
DSO90000A-805 GPIB Card-interface
DSO90000A-807 1 M ohm, adapter with a 500 MHz passive probe
DSO90000A-820 DVD-RW
DSO90000A-821 Additional Precision BNC to SMA adapters, qty 2
DSO90000A-822 External Touchscreen Monitor for Infiniium
DSO90000A-1A7 ISO17025 Compliant Calibration
Presales memory options
DSO90000A-20M 20M Memory / CH Upgrade
DSO90000A-100 100M Memory / CH Upgrade
DSO90000A-200 200M Memory / CH Upgrade
DSO90000A-500 500M Memory / CH Upgrade
DSO90000A-50M 50M Memory / CH Upgrade*
DSO90000A-01G 1G Memory / CH Upgrade
Mount your 90000 Series scope in a19”
(487 mm) rack with option 1CM
Quickly remove your hard drive for
additional security with Option 801
Model Bandwidth Channels Sample rate Standard memory
DSA/DSO91304A 13 GHz 4 40 GSa/s 20 Mpts/50 Mpts (DSA)
DSA/DSO91204A 12 GHz 4 40 GSa/s 20 Mpts/50 Mpts (DSA)
DSA/DSO90804A 8 GHz 4 40 GSa/s 20 Mpts/50 Mpts (DSA)
DSA/DSO90604A 6 GHz 4 20 GSa/s 20 Mpts/50 Mpts (DSA)
DSA/DSO90404A 4 GHz 4 20 GSa/s 20 Mpts/50 Mpts (DSA)
DSA/DSO90254A 2.5 GHz 4 20 GSa/s 20 Mpts/50 Mpts (DSA)
Infiniium DSA/DSO90000A Series oscilloscopes
* Standard on DSA version oscilloscopes
