8
Table 1-6 Uncorrected system performance
(correction: off, 23°C ± 5°C)
Description Specification
300 kHz to 3 GHz
Directivity 25 dB
Source match 25 dB
Load match 15 dB
Transmission tracking ±1.0 dB
Reflection tracking ±1.0 dB
Table 1-7 Test port output frequency
Description Specification Supplemental information
Range
E5061A 300 kHz to 1.5 GHz
E5062A 300 kHz to 3 GHz
Resolution 1 Hz
Source stability
E5061A/E5062A ±5 ppm (5°C to 40°C, typical)
CW accuracy
E5061A/E5062A ±5 ppm, 23°C ± 5°C
Uncorrected system performance
Test port output (source)
