12 of 32 PN: 11410-00485 Rev. M MT8212E and MT8213E TDS
Specifications Cell Master™ MT8212E and MT8213E
CDMA Signal Analyzers (Options 0042, 0043, 0033)
Setup Parameters
PN Setup PN Trigger (No Trigger, GPS, External), PN Search Type (Auto, Manual), PN Offset
Walsh Codes 64, 128
Measurement Speed Fast, Normal, Slow
External Trigger Polarity Rising, Falling
Number of Carriers 1 to 5
Carrier Bandwidth 1.23, 1.24, 1.25 MHz
Frequency Center, Signal Standard, Channel #, Closest Channel, Decrement/Increment Channel
Amplitude Scale/Division, Power Offset, Auto Range, Adjust Range, Units (dBm/Watts)
Sweep Single/Continuous, Trigger Sweep
Save/Recall Setup, Measurement, Screen Shot (save only), to Internal/External Memory
Measurement Summary Screens Overall Measurements, RF Measurements, Signal Quality Measurements
RF Measurements (Option 0042) (Temperature range 15 ºC to 35 ºC)
RF Channel Power Accuracy ± 1.5 dB, ± 1.0 dB typical, (RF input –50 dBm to +20 dBm)
Demodulation (Option 0043) (Temperature range 15 ºC to 35 ºC)
Frequency Error ± 10 Hz + time base error, 99 % confidence level (in slow mode)
Rho Accuracy ± 0.005, for Rho > 0.9
Residual Rho > 0.995, typical, > 0.99 maximum, (RF input –50 dBm to +20 dBm)
PN Offset 1 x 64 chips
Pilot Power Accuracy ± 1.0 dB typical, relative to channel power
Tau ± 0.5 µs typical, ± 1.0 µs maximum
Over-the-Air (OTA) Measurements (Option 0033)
Pilot Scanner Nine strongest pilots
Multipath Scanner Multipath power of six signals relative to strongest pilot
Limit Test Average of ten tests compared to limit
Measurements
RF
(Option 0042)
Demodulation
(Option 0043)
Over-the-Air (OTA)
(Option 0033)
Pass/Fail
(User Editable)
Channel Spectrum
Channel Power
Occupied Bandwidth
Peak-to-Average Power
Spectral Emission Mask
Multi-carrier ACPR
RF Summary
Code Domain Power Graph
Pilot Power
Channel Power
Noise Floor
Rho
Carrier Feed Through
Tau
RMS Phase Error
Frequency Error
Abs/Rel/ Power
Pilot
Page
Sync
Q Page
Code Domain Power Table
Code
Status
Power
Multiple Codes
Code Utilization
Modulation Summary
Pilot Scanner (Nine)
PN
E
C
/I
O
Tau
Pilot Power
Channel Power
Pilot Dominance
Multipath Scanner (Six)
E
C
/I
O
Tau
Channel Power
Multipath Power
Limit Test – 10 Tests Averaged
Rho
Adjusted Rho
Multipath
Pilot Dominance
Pilot Power
Pass/Fail Status
Channel Power
Occupied Bandwidth
Peak-to-Average Power
Spectral Mask Test
Frequency Error
Channel Frequency
Pilot Power
Noise Floor
Rho
Carrier Feed Through
Tau
RMS Phase Error
Code Utilization
Measured PN
Pilot Dominance
Multipath Power
