BTS Master™ MT8221B Base Station Analyzer Specifications
Interference Analyzer (Option 0025)
Measurements Spectrum
Field Strength
Occupied Bandwidth
Channel Power
Adjacent Channel Power (ACPR)
AM/FM/SSB Demodulation (Wide/Narrow FM, Upper/Lower SSB), (audio out only)
Carrier-to-Interference ratio (C/I)
Spectrogram (Collect data up to one week)
Signal Strength (Gives visual and aural indication of signal strength)
Received Signal Strength Indicator (RSSI) (collect data up to one week)
Gives visual and aural indication of signal strength
Signal ID (up to 12 signals)
Center Frequency
Bandwidth
Signal Type (FM, GSM, W-CDMA, CDMA, Wi-Fi)
Closest Channel Number
Number of Carriers
Application Options Signal-to-Nose Ratio (SNR) >10 dB
Bias-Tee (On/Off), Impedance (50 Ω, 75 Ω, Other)
Channel Scanner (Option 0027)
Number of Channels 1 to 20 Channels (Power Levels)
Measurements Graph/Table, Max Hold (On/5 sec/Off), Frequency/Channel, Current/Maximum, Dual Color
Scanner Scan Channels, Scan Frequencies, Scan Customer List, Scan Script Master™
Amplitude Reference Level, Scale
Custom Scan Signal Standard, Channel, # of Channels, Channel Step Size, Custom Scan
Frequency Range 150 kHz to 7.1 GHz
Frequency Accuracy ±10 Hz + Time base error
Measurement Range -110 dBm to +30 dBm
Application Options Bias-Tee (On/Off), Impedance (50 Ω, 75 Ω, Other)
Gated Sweep (Option 0090)
Mode Spectrum Analyzer, Sweep
Trigger External TTL
Setup Gated Sweep (On/Off)
Gate Polarity (Rising, Falling)
Gate Delay (0 to 65 ms typical)
Gate Length (1 µs to 65 ms typical)
Zero Span Time
Zero Span IF Output (Option 0089)
Mode Spectrum Analyzer/Span/Zero Span
Center Frequency 140 MHz ± 130 kHz
Output Level -25 dBm typical
Reference Level -57 to +30 dBm (Preamp Off)
-87 to -40 dBm (Preamp On)
IF Bandwidths Up to 30 MHz (3 dB bandwidth)
Connector BNC female
