BTS Master™ MT8221B Base Station Analyzer Specifications
W-CDMA/HSDPA Signal Analyzers (Options 0044, 0045 or 0065, 0035)
Measurements
RF
(Option 0044)
Demodulation
(Option 0045 or 0065)
Over-the-Air (OTA)
(Option 0035)
Pass/Fail
(User Editable)
Band Spectrum
Channel Spectrum
Channel Power
Occupied Bandwidth
Peak-to-Average Power
Spectral Emission Mask
Single carrier ACLR
Multi-carrier ACLR
Code Domain Power Graph
P-CPICH Power
Channel Power
Noise Floor
EVM
Carrier Feed Through
Peak Code Domain Error
Carrier Frequency
Frequency Error
Control Channel Power
Abs/Rel/Delta Power
CPICH, P-CCPCH
S-CCPCH, PICH
P-SCH, S-SCH
HSDPA
Power vs. Time
Constellation
Code Domain Power Table
Code, Status
EVM, Modulation Type
Power, Code Utilization
Power Amplifier Capacity
Codogram
Scrambling Code Scanner (Six)
Scrambling Codes
CPICH
Ec/Io
Ec
Pilot Dominance
OTA Total Power
Multipath Scanner (Six)
Six Multipaths
Tau
Distance
RSCP
Relative Power
Multipath Power
Max Output Power
Frequency Error
EVM
CPICH
Occupied Bandwidth
Spectral Mask
ACLR
PCDE
P-CCPCH
S-CCPCH
Code Spread 3
PICH
Code 128
Test Models
1 (16), (32), (64)
2
3 (16), (32)
4 (+CPICH), (-CIPCH)
5 (2 HS), (4 HS), (8 HS)
Setup Parameters
Scrambling Code, Threshold Auto, Manual
User Selectable Scrambling Code, S-CCPCH Spread, S-CCPCH Code, PICH Code, Threshold,
Max Amp Power, CPICH Power, Frequency Error Average
Maximum Spreading Factor 256, 512
Frequency Center, Signal Standard, Channel #, Closest Channel, Decrement/Increment Channel
Amplitude Scale/Division, Power Offset, Auto Range, Adjust Range, Units (dBm/Watts)
Marker Six Markers, Table On/Off
Sweep Single/Continuous, Trigger Sweep
Save/Recall Setup, Measurement, Screen Shot (save only), to Internal/External Memory
Measurement Summary Screens Overall Measurements, RF Measurements, Signal Quality Measurements
RF Measurements (Option 0044)
Frequency Range Bands I – XIV, XVII
RF Channel Power Accuracy ±1.25 dB, ±0.7 dB typical, (temperature range 15 ºC to 35 ºC)
Occupied Bandwidth Accuracy ±100 kHz
Adjacent Channel Leakage Ratio (ACLR) -54 dB/-59 dB ±0.8 dB @ 5 MHz/10 MHz offset, typical, 824 to 894, 1710 to 2170 MHz
-54 dB/-57 dB ±1.0 dB @ 5 MHz/10 MHz offset, typical, 2300 to 2700 MHz
Demodulation (Option 0045 for W-CDMA only or 0065 for W-CDMA and HSDPA)
Frequency Error ±10 Hz + time base error, 99% confidence level
EVM Accuracy ±2.5%, 6% ≤EVM ≤25%
Residual EVM 2.5%
Code Domain Power ±0.5 dB for code channel power >–25 dB,
16, 32, 64 DCPH (test model 1), 16, 32 DCPH (test model 2, 3)
CPICH (dBm) Accuracy ±0.8 dB typical
Over-the-Air (OTA) Measurements (Option 0035)
Scrambling Code Scanner Six strongest Scrambling Codes
Multipath Scanner Six multipaths’ power relative to strongest pilot
