BTS Master™ MT8221B Base Station Analyzer Specifications
IEEE 802.16 Mobile WiMAX Signal Analyzers (Options 0066, 0067, 0037)
Measurements
RF
(Option 0066)
Demodulation
(Option 0067)
Over-the-Air (OTA)
(Option 0037)
Pass/Fail
(User Editable)
Channel Spectrum
Channel Power
Occupied Bandwidth
Power vs. Time
Channel Power
Preamble Power
Downlink Burst Power
Uplink Burst Power
ACPR
Constellation
RCE (RMS/Peak)
EVM (RMS/Peak)
Frequency Error
CINR
Base Station ID
Sector ID
Spectral Flatness
Adjacent Subcarrier Flatness
EVM vs. Subcarrier/Symbol
RCE (RMS/Peak)
EVM (RMS/Peak)
Frequency Error
CINR
Base Station ID
Sector ID
DL-MAP (Tree View)
Channel Power Monitor
Preamble Scanner (Six)
Preamble
Relative Power
Cell ID
Sector ID
PCINR
Dominant Preamble
Base Station ID
Channel Power
Occupied Bandwidth
Downlink Bust Power
Uplink Burst Power
Preamble Power
Crest Factor
Frequency Error
Carrier Frequency
EVM
RCE
Sector ID
Setup Parameters
Zone Type PUSC
DL-MAP Auto Decoding Convolutional Coding (CC), Convolutional Turbo Coding (CTC)
Bandwidths 3.50, 5.00, 7.00, 8.75, 10.00 MHz
Cyclic Prefix Ratio (CP) 1/8
Span 5, 10, 20, 30 MHz
Frame Lengths 5, 10 msec
Demodulation Auto, Manual, FCH
Frequency Center, Signal Standard, Channel #, Closest Channel, Decrement/Increment Channel
Amplitude Scale/Division, Power Offset, Auto Range, Adjust Range
Sweep Single/Continuous, Trigger Sweep
Save/Recall Setup, Measurement, Screen Shot (save only), to Internal/External Memory
Measurement Summary Screens Overall Measurements, RF Measurements, Signal Quality Measurements
RF Measurements (Option 0066)
RF Channel Power Accuracy ±1.5 dB, ±1.0 dB typical, (RF input -50 to +20 dBm)
Demodulated Signal Analyzer (Option 0067)
Frequency Error 0.02 ppm + time base error, 99% confidence level
Residual EVM (rms) 2.5% typical, 3.0% maximum, (RF Input -50 dBm to +20 dBm)
Over-the-Air (OTA) Measurements (Option 0037)
Channel Power Monitor Over time (one week), measurement time interval 1 to 60 sec
Preamble Scanner Six Strongest Preambles
Auto Save Yes
GPS Logging Yes
