BTS Master™ MT8221B Base Station Analyzer Specifications
Master Software Tools (for your PC)
Database Management
Full Trace Retrieval Retrieve all traces from instrument into one PC directory
Trace Catalog Index all traces into one catalog
Trace Rename Utility Rename measurement traces
Group Edit Titles, subtitles, plot scaling, markers and limit lines, simultaneously on similar files
DAT File Converter Converts HHST files to MST file format and vice-versa
Data Analysis
Trace Math and Smoothing Compare multiple traces
Data Converter Convert from/to Return Loss/ VSWR/ Cable Loss/ DTF and also into Smith Charts
Measurement Calculator Translates into other units
Report Generation
Report Generator Includes GPS, power level, and calibration status along with measurements
Edit Graph Change scale, limit lines, and markers
Report Format Create reports in HTML for PDF format
Export Measurements Export measurements to *.s2p, *.jpg or *.csv format
Notes Annotate measurements
Mapping (GPS Required)
Spectrum Analyzer Mode MapInfo, MapPoint
Mobile WiMAX OTA Option Google Earth, Google Maps, MapInfo
Folder Spectrogram (Spectrum Monitoring for Interference Analysis and Spectrum Clearing)
Folder Spectrogram – 2D View Creates a composite file of multiple traces
Peak Power, Total Power, Peak Frequency, Histogram, Average Power (Max/Min)
File Filter (Violations over limit lines or deviations from averages)
Playback
Video Folder Spectrogram – 2D View Create AVI file to export for management review/reports
Folder Spectrogram – 3D View Views (Set Threshold, Markers)
- 3D (Rotate X, Y, Z Axis, Level Scale, Signal ID)
- 2D View (Frequency or Time Domain, Signal ID)
- Top Down
Playback (Frequency and/or Time Domain)
List/Parameter Editors
Traces Add, delete, and modify limit lines and markers
Antennas, Cables, Signal Standards Modify instrument’s Antenna, Cable, and Signal Standard List
Product Updates Auto-checks Anritsu website for latest revision firmware
Firmware Upload Upload new firmware into the instrument
Pass/Fail Create, download, or edit Signal Analysis Pass/Fail Limits
VSG Pattern Converter Import user-defined patterns (ASCII text or MATLAB file format required)
Languages Add up to two languages or modify non-English language menus
Mobile WiMAX DL-MAP Parameters
Display Modify display settings
Script Master™
Channel Scanner Mode Automate scan up to 1200 channels, repeat for sets of 20 channels, repeat all channels
GSM/GPRS/EDGE or W-CDMA/HSDPA Mode Automate Signal Analysis testing requirements with annotated how-to pictures
Connectivity
Connections Connect to PC using USB, LAN, or Direct Ethernet connection
Download Download measurements and live traces to PC for storage and analysis
Upload Upload measurements from PC to instrument
Firmware Updates Product Update: download latest firmware version
Remote Access Tool Remote control and monitoring of instrument (via Ethernet port) over the Internet
