BTS Master™ MT8221B Base Station Analyzer Specifications
General Specifications
All specifications and characteristics apply under the following conditions, unless otherwise stated: 1) After 5 minutes of warm-up time, where
the instrument is left in the ON state; 2) All specifications apply when using internal reference; 3) All specifications subject to change without
notice; 4) Typical performance is the measured performance of an average unit; 5) Recommended calibration cycle is 12 months.
Setup Parameters
System Status (Temperature, Battery Info, Serial Number, Firmware Version, Options Installed)
Self Test, Application Self Test
GPS (see Option 0031)
System Options Name, Date and Time, Ethernet Configuration, Brightness, Volume
Language (English, French, German, Spanish, Chinese, Japanese, Korean, Italian, User defined)
Reset (Factory Defaults, Master Reset, Update Firmware)
File Save, Recall, Delete, Directory Management
Save/Recall Setups, Measurements, Screen Shots Jpeg (save only)
Delete Selected File, All Measurements, All Mode Files, All Content
Directory Management Sort Method (Name/Type/Date), Ascend/Descend, Internal/USB, Copy, Format USB
Internal Trace/Setup Memory >30,000 traces
External Trace/Setup Memory Limited by size of USB Flash drive
Mode Switching Auto-Stores/Recalls most recently used Setup Parameters in the Mode
Connectors
RF Out Type N, female, 50 Ω, Maximum Input +23 dBm, ±50 VDC, (Reflection In)
RF In Type N, female, 50 Ω, Maximum Input +30 dBm, ±50 VDC
GPS SMA. female
T1, T3 Bantam Jacks
E1 RJ48C
External Power 5.5 mm barrel connector, 12 to 15 VDC, <5.0 Amps
LAN Connection RJ48C, 10/100 Mbps, Connect to PC or LAN for Remote Access
USB Interface (2) Type A, Connect Flash Drive and Power Sensor
USB Interface 5-pin mini-B, Connect to PC for data transfer
Headset Jack 2.5 mm barrel connector
External Reference In BNC, female, 50 Ω, Maximum Input +10 dB
Reference Out BNC, female, 50 Ω, 10 MHz
External Trigger In/Clock Recovery BNC, female, 50 Ω, Maximum Input ±50 VDC
IF Out BNC, female, 50 Ω, 140 MHz
Display
Size 8.4”
Resolution 800 x 600
Battery
Type Li-Ion
Battery Operation 2.5 hours, typical
Electromagnetic Compatibility
European Union CE Mark, EMC Directive 89/336/EEC, 92/31/EEC, 93/68/EEC and
Low Voltage Directive 73/23/EEC, 93/68/EEC
Australia and New Zealand C-tick N274
Interference EN 61326-1
Emissions EN 55011
Immunity EN 61000-4-2/-4-3/-4-4/-4-5/-4-6/-4-11
Safety
Safety Class EN 61010-1 Class 1
Product Safety IEC 60950-1 when used with Company supplied Power Supply
Environmental
Operating Temperature -10 ºC to 55 ºC
Maximum Humidity 85%
Shock MIL-PRF-28800F Class 2
Storage -51 ºC to 71 ºC
Altitude 4600 meters, operating and non-operating
Size and Weight
Size 315 x 211 x 94 mm, (12.4 x 8.3 x 3.7 in)
Weight 4.9 kg, (10.7 lbs)
