BTS Master™ MT8221B Base Station Analyzer Specifications
Cable and Antenna Analyzer
Measurements
Measurements VSWR 1-port Phase
Return Loss 2-port Phase
Cable Loss 2-port Gain
Distance-to-Fault (DTF) Return Loss Smith Chart
Distance-to-Fault (DTF) VSWR
Setup Parameters
Frequency Start/Stop, Signal Standard, Start Cal
DTF Start/Stop, DTF Aid, Units (m/ft), Cable Loss, Propagation Velocity, Cable, Windowing
Windowing Rectangular, Normal Side Lobe, Low Side Lobe, Minimum Side Lobe
Amplitude Top, Bottom Auto Scale, Full Scale
Sweep Run/Hold, Single/Continuous, RF Immunity (High/Low), Data Points, Averaging/Smoothing,
Output Power (High/Low)
Data Points 137, 275, 551
Markers Markers 1-6 each with a Delta Marker, Marker to Peak/Valley, Marker Table (On/Off)
Traces Recall, Copy to Display Memory, No Trace Math, Trace ± Memory, Trace Overlay (On/Off)
Limit Line On/Off, Single Limit, Multi-segment (41), Limit Alarm, Clear
Limit Line Edit Frequency, Amplitude, Add Point, Delete Point, Next Point Left/Right, Move Limit
Calibration Start Cal, 1/2-port, Low/High Power, Standard/FlexCal™, DUT Connector, Configure DUT
File Save, Recall, Delete, Directory Management
Save/Recall Setups, Measurements, Screen Shots Jpeg (save only)
Delete Selected File, All Measurements, All Mode Files, All Content
Directory Management Sort Method (Name/Type/Date), Ascend/Descend, Internal/USB, Copy, Format USB
Application Options Bias-Tee (On/Off), Impedance (50Ω, 75Ω, Other)
Frequency
Frequency Range 400 MHz to 4 GHz
Frequency Accuracy ±3.0 ppm
Frequency Resolution 1 kHz (RF immunity low)
100 kHz (RF immunity high)
Output Power
High -7 dBm, typical, 1 or 2-port
Low -40 dBm, typical, 2-port
Dynamic Range
400 MHz to 3.0 GHz 80 dB
>3.0 GHz to 4.0 GHz 70 dB
Interference Immunity
On-Channel +17 dBm @ >1.0 MHz from carrier frequency
On-Frequency +10 dBm within ±10 kHz from the carrier frequency
Measurement Speed
Return Loss ≤4.5 msec/data point, RF immunity low, typical
Distance-to-Fault ≤4.5 msec/data point, RF immunity low, typical
Return Loss
Measurement Range 0 to 60 dB
Resolution 0.01 dB
VSWR
Measurement Range 1 to 65
Resolution 0.01
Cable Loss
Measurement Range 0 to 30 dB
Resolution 0.01 dB
2-Port Gain
Measurement Range -120 to 100 dB
Resolution 0.01 dB
