BTS Master™ MT8221B Base Station Analyzer Specifications
CDMA2000 1xEV-DO Signal Analyzers (Option 0062, 0063, 0034)
Measurements
RF
(Option 0062)
Demodulation
(Option 0063)
Over-the-Air (OTA)
(Option 0034)
Pass/Fail
(User Editable)
Channel Spectrum
Channel Power
Occupied Bandwidth
Peak-to-Average Power
Power vs. Time
Pilot & MAC Power
Channel Power
Frequency Error
Idle Activity
On/Off Ratio
Spectral Emission Mask
Multi-carrier ACPR
MAC Code Domain Power Graph
Pilot & MAC Power
Channel Power
Frequency Error
Rho Pilot
Rho Overall
Data Modulation
Noise Floor
MAC Code Domain Power Table
Code
Status
Power
Code Utilization
Data Code Domain Power
Active Data Power
Data Modulation
Rho Pilot
Rho Overall
Maximum Data CDP
Minimum Data CDP
Pilot Scanner (Nine)
PN
Ec/Io
Tau
Pilot Power
Channel Power
Pilot Dominance
Mulitpath Scanner (Six)
Ec/Io
Tau
Channel Power
Multipath Power
Channel Power
Occupied Bandwidth
Peak-to-Average Power
Carrier Frequency
Frequency Error
Spectral Mask
Noise Floor
Pilot Power
RMS Phase Error
Tau
Code Utilization
Measured PN
Pilot Dominance
Mulitpath Power
Setup Parameters
PN Setup PN Trigger (No Trigger, GPS, External), PN Search Type (Auto, Manual), PN Offset
Walsh Codes 64, 128
Measurement Speed Fast, Normal, Slow
External Trigger Polarity Rising, Falling
Slot Type Auto, Active, Idle
Number of Carriers\ 1 to 5
Carrier Bandwidth 1.23, 1.24, 1.25 MHz
Frequency Center, Signal Standard, Channel #, Closest Channel, Decrement/Increment Channel
Amplitude Scale/Division, Power Offset, Auto Range, Adjust Range, Units (dBm/Watts)
Sweep Single/Continuous, Trigger Sweep
Save/Recall Setup, Measurement, Screen Shot (save only), to Internal/External Memory
Measurement Summary Screens Overall Measurements, RF Measurements, Signal Quality Measurements
RF Measurements (Option 0062)
RF Channel Power Accuracy ±1.5 dB, ±1.0 dB typical, (RF input -50 to +20 dBm)
Demodulation (Option 0063)
EV-DO Compatibility Rev 0 and Rev A
Frequency Error ±10 Hz + time base error, 99% confidence level
Rho Accuracy ±0.01, for Rho >0.9
Residual Rho >0.995 typical, >0.99, maximum (RF input -50 to +20 dBm)
PN Offset Within 1 x 64 chips
Pilot Power Accuracy ±1.0 dB typical, relative to channel power
Tau ±0.5 µs typical, ±1.0 µs maximum
Over-the-Air (OTA) Measurements (Option 0034)
Pilot Scanner Nine strongest pilots
Multipath Scanner Six multipaths’ power relative to strongest pilot
