BTS Master™ MT8221B Base Station Analyzer Specifications
Ordering Information
MT82221B Description
400 MHz to 4 GHZ Cable and Antenna Analyzer
150 kHz to 7.1 GHz Spectrum Analyzer
150 kHz to 7.1 GHz Power Meter
Options
MT8221B-0010 Bias-Tee
MT8221B-0031 GPS Receiver (Requires Antenna P/N 2000-1528-R)
MT8221B-0019 High-Accuracy Power Meter
MT8221B-0025 Interference Analyzer
MT8221B-0027 Channel Scanner
MT8221B-0089 Zero-Span IF Output
MT8221B-0090 Gated Sweep
MT8221B-0023 Vector Signal Generator
MT8221B-0040 GSM/GPRS/EDGE RF Measurements
MT8221B-0041 GSM/GPRS/EDGE Demodulation
MT8221B-0044 W-CDMA/HSDPA RF Measurements
MT8221B-0045 W-CDMA Demodulation
MT8221B-0065 W-CDMA/HSDPA Demodulation
MT8221B-0035 W-CDMA/HSDPA Over-the-Air Measurements*
MT8221B-0060 TD-SCDMA/HSDPA Measurements
MT8221B-0061 TD-SCDMA/HSDPA Demodulation
MT8221B-0038 TD-SCDMA/HSDPA Over-the-Air Measurements
MT8221B-0042 cdmaOne/CDMA2000 1X RF Measurements
MT8221B-0043 cdmaOne/CDMA2000 1X Demodulation
MT8221B-0033 cdmaOne/CDMA2000 1X Over-the-Air Measurements *
MT8221B-0062 CDMA2000 1xEV-DO RF Measurements
MT8221B-0063 CDMA2000 1xEV-DO Demodulation
MT8221B-0034 CDMA2000 1xEV-DO Over-the-Air Measurements *
MT8221B-0046 IEEE 802.16 Fixed WiMAX RF Measurements
MT8221B-0047 IEEE 802.16 Fixed WiMAX Demodulation
MT8221B-0066 IEEE 802.16 Mobile WiMAX RF Measurements
MT8221B-0067 IEEE 802.16 Mobile WiMAX Demodulation
MT8221B-0037 IEEE 802.16 Mobile WiMAX Over-the-Air Measurements
MT8221B-0051 T1 Analyzer
MT8221B-0052 E1 Analyzer
MT8221B-0053 T3/T1 Analyzer
MT8221B-0098 Standard Calibration to Z540
MT8221B-0099 Premium Calibration to Z540 plus test data
*Requires GPS Receiver Option 0031
Power Sensors (For complete ordering information see the respective datasheets of each sensor)
Model Number Description
PSN50 High Accuracy RF Power Sensor, 50 MHz to 6 GHz, +20 dBm
MA24104A Inline High Power Sensor, 600 MHz to 4 GHz, + 51.76 dBm
MA24106A High Accuracy RF Power Sensor, 50 MHz to 6 GHz, +23 dBm
MA24108A Microwave USB Power Sensor, 10 MHz to 8 GHz, +20 dBm
MA24118A Microwave USB Power Sensor, 10 MHz to 18 GHz, +20 dBm
