Upload Utility | 41
8.0 Upload Utility
Log file data can be uploaded to a personal computer using the RS-232
connector. To use the RS-232 connector, attach the RS-232 cable between the
HI-2200 RF Survey Meter and the computer.
Install Upload Utility
The following installation instructions are intended for use with one of the
Microsoft® Windows® operating systems.
1. Download Upload Utility from the ETS-Lindgren website,
www.ets-lindgren.com . Point to Resources, click Software/Firmware,
and then click Upload Utility. Follow the instructions to download.
2. To begin the installation program, click Setup.exe.
Start Upload Utility
1. Click Start, All Programs, and then click HIupload. The Upload Utility
splash screen displays.
2. Select the default communications port you will be connecting to.
3. Upload Utility is now running with the Incoming Data tab highlighted.
Verify that the proper communication settings are selected. Following
are the default settings:
Baud: 9600
Parity: None
Data Bits: 8
Stop Bit: 1
You are now ready to upload log file data to the computer.
