Operation | 27
6.0 Operation
Before connecting any components or
operating the unit, follow the safety information
in the ETS-Lindgren Product Information
Bulletin included with your shipment.
Connecting the Probe
1. Connect the probe to the receptacle
located at the top of the HI-2200
RF Survey Meter. To avoid damage
to the connection, align the
indexing marks and pins on the
probe connector with the
receptacle.
2. Turn the connector sleeve until it is
finger tight to secure the probe into
place. Do not use any mechanical
means to tighten the probe.
Do not connect a probe to the HI-2200 while the meter is powered on.
The HI-2200 must be powered off before it will recognize a
newly-added probe.
