Operation | 29
Powering Up
Press POWER on the HI-2200. The start up screen will display briefly, followed
by the initial monitoring screen.
P OSSIBLE E RROR M ESSAGES AT S TART U P
Error Message Description
No Probe A probe is not connected to the HI-2200.
No Calib The attached probe is not matched to the HI-2200.
Low Field The probe indication is less than 0.3 V/m.
If a probe is attached while the HI-2200 is powered on, turn the meter
off and then on again to recognize the probe.
Probe Units
From the monitoring screen press the function key under Units to step through
the options for the attached probe.
U NITS FOR THE E-F IELD P ROBE
Field Intensity: V/m—Volts per meter
Plane Wave Equivalent
Power Density:
• μW/cm 2
—Microwatts per
square centimeter
• mW/cm 2
—Milliwatts per
square centimeter
• W/m 2
—Watts per square
meter
