ETS-Lindgren HI-2200 RF Survey Meter - Manual (Page 18)

18 | Specifications
Model C300 E-Field Probe
E-Field Probe Dimension: • Overall Length:
260 mm (10.3 in)
• Sensor Cover:
60 mm x 71.1 mm
(2.4 in x 2.8 in)
M ODEL C310 E-F IELD P ROBE
Model C310 E-Field Probe
Sensor Type: Electric Field
Detection: Isotropic (Total Field Indication)
Conformance: International Commission on
Non-Ionizing Radiation Protection
(ICNIRP) Occupational levels
Frequency Range: 100 kHz to 8 GHz
Frequency Response: ± 3 dB to actual limits as specified in
the standard
Dynamic Range: <1%–999% of ICNIRP Standard
Resolution: Limited to 1%
Isotropic Response: ± 0.7 dB @ 400 MHz
E-Field Probe Dimension: • Overall Length:
260 mm (10.3 in)
• Sensor Cover:
60 mm x 71.1 mm
(2.4 in x 2.8 in)
