16 | Specifications
Model E100 E-Field Probe
Overload Withstand: >1200 V/m
Isotropic Response: ± 0.7 dB @ 400 MHz
Units of Measure: V/m, µW/cm
2 , mW/cm
2
, W/m
2
E-Field Probe Dimension: • Overall Length:
260 mm (10.3 in)
• Sensor Cover:
60 mm x 71.1 mm
2.4 in x 2.8 in
M ODEL H200 H-F IELD P ROBE
Model H200 H-Field Probe
Sensor Type: Magnetic Field
Detection: Isotropic (Total Field Indication)
Frequency Range: 5 MHz to 300 MHz
Frequency Response: ± 1 dB (10 MHz to 100 MHz)
± 2.5 dB (5 MHz to 300 MHz)
Dynamic Range: 30 mA/m – 10 A/m (Single Range)
Overload Withstand: 20 A/m
Isotropic Response: ± 0.7 dB @ 100 MHz
Units of Measure: A/m, mA/m µW/cm
2 , mW/cm
2
, W/m
2
E-Field Probe Dimension: • Overall Length:
260 mm (10.3 in)
• Sensor Cover (Diameter):
60 mm (2.4 in)
