Application | 37
7.0 Application
Begin Logging
From the main navigational menu use the UNITS key to select the unit of
measure to use for logging. The unit of measure cannot be changed while
logging is in progress.
• Verify that all settings are configured according to your test plan. On
the Setup menu, select Log Mode, and then select Single,
Continuous, or Spatial (see Setup on page 30 for more information).
Selecting any of these settings will create a new log file.
• Data points must be saved or appended into a file before another new
log file can be created.
• Press the Back key to exit the Setup menu.
• Press one of the LOG keys to begin logging.
• For single point logging: The LOG key must be operated to save or log
each data point.
• For continuous logging: Press the LOG key once to begin logging and
again to stop the logging process
Once logging is complete, the available options are to Save, Append, Delete, or
View the data logged
• Save—The logged data will be saved in the new file and the function
key menu will become available at the bottom of the screen.
• Append—The most recent data is added to the same (current) file.
This option is not available in Spatial Log mode.
• Delete—Removes the current data points from memory
• View—Allows the data to be seen before choosing to save or delete.
