30 | Operation
U NITS FOR THE H-F IELD P ROBE
Field Intensity:
• A/m—Amps per meter
• mA/m—Milliamps per meter
Plane Wave Equivalent
Power Density:
mW/cm
2
—Milliwatts per square
centimeter
U NITS FOR THE C ONFORMAL F IELD P ROBES
The ETS-Lindgren Conformal Field Probes provide a measure of field intensity
tailored to conform to the industry standard. The sum of the resulting
contributions is displayed as a percent of the allowable exposure limits.
Logged data will indicate the unit of measure that was selected during logging
Setup
Under the Setup menu there are many options that will assist in configuring the
attached probe. The options are explained here; for additional information, see
Menu Tree on page 47.
L OG M ODE
Log Mode allows the selection of single point, continuous, or spatial logging.
• Single point logging will collect one data point each time the log key is
pressed (not more than one point per second).
• Continuous logging will log one data point per second beginning when
the log key is pressed and ending when the log key is pressed again.
• Spatial averaging mode changes the default settings so the meter is
set to collect a running average. The display mode is updated so the
primary number displayed is the AVG value. When spatial averaging is
activated a new log file must be created for each set of data collected.
The append feature is not available in this mode. The meter logs one
data point per second beginning when the log key is pressed and
ending when log is pressed again.
