- 46 -
Model 12-1012 Users’ Manual Version 13.08
Associated Equipment Corp.
5043 Farlin Ave. 800-949-1472(US)
St. Louis, MO 63115 314-385-5178 (Outside US)
RESULTS: Good
12.40V 419 CCA
Int.R: 6.43mΩ
LIFE: 76%
3. Pressing key once will scroll down to the ‘Last Test Results’
Fig. 67 below.
4. Press key will proceed to display the last test results depending
the type of test you had performed earlier. (Fig. 68)
5. To view the next page, press or key to get to the page you
want.
Some examples below are: (Figs. 69, 70, 71 & 72)
Figure 67
Figure 68
Figure 69 Figure 70
Figure 71 Figure 72
Select Test
New: ClearMemory
Continue Test...
LastTest Results
ENGINE GROUND
Results: OK
Resistance is
within limits.
CRANKING TEST
MinVolts: 10.26V
VoltDrop: Normal
Results: OK
NO LOAD TEST
ChrgVolts: 13.96V
Results: GOOD
Enter to proceed
LOAD TEST
MaxCharge: 13.36V
Results: LOW
Check Belt/Alt
