9.1– Begin Testing
1. With engine OFF, place the vehicle transmission in NEUTRAL for
Manual and PARK for Automatic then apply the parking brake.
2. Connect the analyzer to the battery terminals and the display will light
up as shown (Fig 41).
3. After you have made your choice, selecting either “New: Clear Memory”
or “Continue…Test” will proceed to the display below: (Fig. 42)
4. From the main MENU, select ‘Starter Test’ by scrolling down using
key. (Fig.43)
Figure 41
Figure 43
Figure 42
Select Test
New: ClearMemory
Continue Test...
LastTest Results
Battery Test
Grounding Test
Starter Test
Alternator Test
Battery Test
Grounding Test
Starter Test
Alternator Test
