- 10 -
Model 12-1012 Users’ Manual Version 13.08
Associated Equipment Corp.
5043 Farlin Ave. 800-949-1472(US)
St. Louis, MO 63115 314-385-5178 (Outside US)
4.0 - The Battery Electrical System Analyzer
4.1 – MODEL 12-1012
4.2 - Keypad Functions:
Figure 1
Figure 2
6
1
2
5
7
8
4
3
Red Clamp to
battery positive
( + ) post.
USB port for
connection
to PC.
Black Clamp to
battery negative
( - ) post.
