- 43 -
Model 12-1012 Users’ Manual Version 13.08
Associated Equipment Corp.
5043 Farlin Ave. 800-949-1472(US)
St. Louis, MO 63115 314-385-5178 (Outside US)
Now, switch ON all loads (Head Lights, Radio, Air-condition, Heater, etc)
and press enter key will display: (Fig.59)
Make sure that all electrical loads (lights, air-condition, etc) are ON.
Rev the engine up to 2,000 ~ 2,500 RPM by referring to the dashboard
meter, then press key and maintain it for about 10 seconds and
release the pedal. The maximum and minimum voltages values will be
captured.
After that press key again and it show as below (Fig 60.)
With the captured readings, analysis can done by referring to the limits as
indicated that MAX voltage should exceed 13.5V (max. voltage at 2,000
RPM) and MIN voltage should be more than 12.5V (min voltage during
idling speed).
9. Press key will proceed to show the results of the test:
Figure 60
Figure 61
Figure 59
Average
Charging volts.
Normal
Charging range
Loading Test
at 2,000 RPM
Captured Volts
readings
Rev engine up to
2,000 rpm
Enter
Continue this
rpm for 10 sec.
2000RPM 13.89V
Max 13.96V >13.5V
Min 13.76V >12.5V
Enter to proceed
LOAD TEST
ChrgVolts: 13.96V
Results: GOOD
