7. Press key again and it will starts analyzing (Fig. 34)
8. Once it has finished analyzing, it will prompt you with an instruction
(Fig. 35) stating that you have should unclamp the Black tester clip from
the engine or chassis body and transfer to the battery negative [-]
terminal within 20 seconds time limit if not the testing procedure has to
be repeated again as the gathered data will be lost.
9. Once the Black clip is clamped onto the battery [-] terminal, the
Analyzer display will light up as shown. (Fig. 36)
Figure 34
Figure 35
Analysing...
Please Wait!
ıııııııııııııııı
Now clamp the
Black clip to
battery [-] post
20sec time limit
GROUNDING TEST:
Press Enter to
continue.
Figure 36
