- 4 -
Model 12-1012 Users’ Manual Version 13.08
Associated Equipment Corp.
5043 Farlin Ave. 800-949-1472(US)
St. Louis, MO 63115 314-385-5178 (Outside US)
3. Starter Test:
Checks the cranking effectiveness of the battery to predict when the
battery will fail to crank a vehicle basing on voltage profiles with
results and recommendations display.
4. Alternator Test:
This test checks the alternator charging condition during load at
2,000 RPM and without load at 3,000 RPM with results and
recommendations display after each test.
This Analyzer is maintenance free and does not require internal batteries.
It powers up when connected to the battery posts during testing or through an
external 12 Volts DC source for later review of the test results.
The operation is fast and simple. When hooked up to the battery posts, the
displayed instructions on the screen will lead you through and a warning tone
to caution you to perform the correct steps. In event that you need assistance,
there is a key. It will display information about each function when selected.
Its result is consistent and repeatable and can be performed numerous times
without heating up the unit. It is very safe as it does not create any sparks
when connected to the battery terminals during testing on the vehicle.
After the test, the results will be stored in its memory and can be reviewed
again later and it is equipped with an USB port to be connected to the PC to
store the results or have it printed out from normal computer printer.
1.2 Specifications:
Operating Voltage:
9V ~ 15V DC (max)
Analyzing Capacity (Amps):
CCA: 100 ~ 1700 EN: 100 ~ 1700
IEC: 100 ~ 1000 DIN: 100 ~ 1000
JIS#: 100 ~ 1700
Battery analyzing time:
Less than 8 seconds.
DC Volts Accuracy: ± 2% Reading
Working Temperature: 0ºC (32
°
F) ~ 50ºC (122
°
F).
Working Humidity:
10% ~ 80 %
Dimensions:
181 x 110 x 90 mm
