- 24 -
Model 12-1012 Users’ Manual Version 13.08
Associated Equipment Corp.
5043 Farlin Ave. 800-949-1472(US)
St. Louis, MO 63115 314-385-5178 (Outside US)
Check the battery ratings and enter it as described in step 10 and 11
(page 17~19) and the results will show as an example below: (Fig. 28)
You will notice that there is no indication of message (Good or Replace)
on the RESULTS instead on LIFE; it indicates “Charge > Test”. It means
that the battery has to be fully charged and repeat the test again.
15.
Pressing the key at any moment will exit and return back to the
previous screen.
7.0 – Battery Ratings Charts
7.1 Japanese Industrial Standard (JIS#) CCA Ratings
Battery Model (JIS#)
CCA Rating
Battery Model (JIS#)
CCA Rating
NEW OLD
WET
MF CMF
SMF
NEW OLD
WET
MF CMF
SMF
26A17R 200 34B17L 280
26A17L 200 34B19R NS40ZA 270 325 400
26A19R 12N24-4 200 220 264 34B19L NS40ZAL 270 325 400
26A19L 12N24-3 200 220 264 34B19RS NS40ZAS 270 325 400
28A19R NT50-N24 250 34B19LS NS40ZALS 270 325 400
28A19L NT50-N24L 250 36B20R NS40Z 275 300 360
32A19R NX60-N24 270 295 36B20L NS40ZL 275 300 360
32A19L NX60-N24L 270 295 36B20RS NS40ZS 275 300 360
26A17R 200 36B20LS NS40ZLS 275 300 360
26B17L 200 38B20R NX60-N24 330 340 410
28B17R 245 38B20RS NT60-N24S 330 340 410
28B17L 245 38B20L NX60-24L 330 340 410
28B19R NS40S 245 38B20LS NX60-24LS 330 340 410
28B19L NS40LS 245 40B20L 330
32B20R NS40 270 40B20R 330
32B20L NS40L 270 42B20L 330
32C24R N40 240 325 400 42B20RS 330
32C24L N40L 240 325 400 42B20LS 330
34B17R 280 46B24L NS60L 325 360 420
Figure 28
RESULTS:
09.76V 38 CCA
Int.R: 70.09mΩ
LIFE:Charge>Test
