Model 12-1012 Users’ Manual Version 13.08
Associated Equipment Corp.
5043 Farlin Ave. 800-949-1472(US)
St. Louis, MO 63115 314-385-5178 (Outside US)
11.0 – View Last Test Results
To view the results of the last test, the MODEL 12-1012 has to be connected to
an external power source by either clamping its clips directly to a 12Volt car
battery or connected to a PC via the USB port.
1. Once power up, the wakeup screen will display as follows:
2. It will run through a self-test and when completed it displays the Main
Menu as shown: (Fig. 66)
Figure 65
Figure 66
Figure 64
Select Test
New: ClearMemory
Continue Test...
LastTest Results
Clamp MODEL 12-1012
to a 12V Battery if it is
not connected to a PC
for viewing Last Test
Results.
PC
