- 42 -
Model 12-1012 Users’ Manual Version 13.08
Associated Equipment Corp.
5043 Farlin Ave. 800-949-1472(US)
St. Louis, MO 63115 314-385-5178 (Outside US)
6. Press key will show the results of the test (Figure 55):
7. If either minimum or maximum charging volts are not within the voltage
range limits then it will display one of the screen as below (Figures 56 &
57) and it will prompt you to check the charging system for the fault.
Testing with load at 2,000 RPM
As more electrical accessories, such as lights, heater, air condition, car
stereos, etc. were used; the electro-motive force decreases and this will
allow more amperage from the alternator to flow into the battery to
compensate for the added load. This test is to check the alternator’s
behavior during loading.
8. Continue from the previous test (either Fig. 55, 56 or 57); proceed to
the next step by pressing key will enter to the display as follows.
(Fig.58)
Figure 58
Figure 55
Figure 56 Figure 57
NO LOAD TEST
ChrgVolts: 13.96V
Results: GOOD
Enter to proceed
NO LOAD TEST
MinCharge: 12.96V
Results: LOW
Check Belt/Alt
NO LOAD TEST
MaxCharge: 15.0V
Results: High
Check Regulator
Switch ON all
The Electrical
Loads, then
press
Enter
