If either minimum or maximum charging volts are not within the voltage
range limits then it will display one of the screen as below (Figures 62& 63)
and it will prompt you to check the alternator system for the fault.
10. To exit the program, pressing the
key at any moment will exit and
return back to the previous screen.
Figure 62 Figure 63
LOAD TEST
MinCharge: 12.45V
Results: LOW
Check Belt/Alt
LOAD TEST
MaxCharge: 13.36V
Results: LOW
Check Belt/Alt
