If it is selected under JIS # (Japanese Industrial Standard) then the
display will prompt you as shown (Fig.19) below.
Refer to the battery model (example: 80D26L or NX110-5L) on the
Cold Cranking Amps (CCA) Table list supplied separately or from this
manual on page 24 & 25 (See example Fig.20 below.)
Press key and the display will show: (Fig.21) below:
Figure 19
Figure 20
Figure 21
JIS# to CCA:
See user manual
for conversion
Enter to proceed
Input Value
Set 500 CCA ⊳
Enter to start..
