3.4.1 Remote Battery Return Bar (Optional)
A remote battery return bar is required to facilitate termination of a high quantity of large cables. The kit contains
all parts shown in Figure 7 and mounts to a customer supplied auxiliary frame (2 " x 9/16").
)LJXUH ² 5HPRWHEDWWHU\UHWXUQEDUFXVWRPHUFRQQHFWLRQVGXDODQGVLQJOHEDUVVKRZQ
Dual bars can be stacked or
installed separately.
Lug Spacing
See Figure 8 for exact dimensions.
Small: 72 sets 1/4" on 5/8" ctrs
Large: 24 sets 3/8" on 1" ctrs or
24 sets 1/2" on 1 ¾" ctrs
0.63
0.63
1.28
1.28
0.27
0.27
1.75
1.06
0.56
0.44
2.00
