030-834-J0 Rev A Page 3 of 34
1.3 Part Numbers and List Options
1.3.1 Cordex CXRF-HP 48-1.2 kW 1RU 19" shelf system, up to 3600W output power, CXCM1 Controller
and GMT fuse distribution (Figure 1)
This product can be ordered under the following part numbers and list options:
Description Part Number/List Option
Cordex CXRF-HP 48-1.2kW, 19" 1RU shelf, 3 modules, w/ GMT fuses ................................................. 030-851-20
[Equipped for one CXCM1 controller and up to three CXRF-HP 48-1.2kW rectifiers] ..................................... *List 0
19" rack, center mount ................................................................................................................................... *List 19
19" rack, flush mount..........................................................................................................................................List 21
23" rack, center mount ......................................................................................................................................List 23
23" rack, flush mount..........................................................................................................................................List 25
Black plastic cover ......................................................................................................................................... *List 58
Distribution w/ 8 GMT fuses ........................................................................................................................... *List 80
40-A load LVD ...................................................................................................................................................List 86
70-A battery LVD ...............................................................................................................................................List 87
CXCM1 controller ........................................................................................................................................... *List 99
Two universal AC line cords, C19R – flying leads, 3.5m each ................................................................ 877-790-19
Two 120Vac line cords, 5-15P plugs, 2.5m each .................................................................................... 877-690-19
Kydex cover for bus bar ........................................................................................................................... 567-837-19
Blank panel for power module slot ................................................................................................... 747-622-20-000
Temperature sensor assembly, 6 ft, 1/4" lug ................................................................................... 747-095-20-071
Temperature sensor assembly, 12 ft, 1/4" lug ................................................................................. 747-095-20-072
Temperature sensor assembly, 24 ft, 1/4" lug ................................................................................. 747-095-20-073
Temperature sensor assembly, 6 ft, 3/8" lug ................................................................................... 747-095-20-074
Temperature sensor assembly, 12 ft, 3/8" lug ................................................................................. 747-095-20-075
Temperature sensor assembly, 24 ft, 3/8" lug ................................................................................. 747-095-20-076
Temperature sensor assembly, 50 ft, 3/8" lug ................................................................................. 747-095-20-077
Temperature sensor assembly, 100 ft, 3/8" lug ............................................................................... 747-095-20-078
Temperature sensor assembly, 50 ft, 1/4" lug ................................................................................. 747-095-20-080
Temperature sensor assembly, 100 ft, 1/4" lug ............................................................................... 747-095-20-081
Temperature sensor assembly, 12 ft, 5/16" lug ............................................................................... 747-095-20-082
GMT fuse, 0.5 A ....................................................................................................................................... 460-004-10
GMT fuse, 1 A .......................................................................................................................................... 460-006-10
GMT fuse, 1.3 A ....................................................................................................................................... 460-081-10
GMT fuse, 1.5 A ....................................................................................................................................... 460-082-10
GMT fuse, 2 A .......................................................................................................................................... 460-083-10
GMT fuse, 3 A .......................................................................................................................................... 460-013-10
GMT fuse, 4 A .......................................................................................................................................... 460-085-10
GMT fuse, 5 A .......................................................................................................................................... 460-084-10
GMT fuse, 7.5 A ....................................................................................................................................... 460-105-10
GMT fuse, 10 A ........................................................................................................................................ 460-069-10
GMT fuse, 15 A ........................................................................................................................................ 460-150-10
* Default option
The above information is valid at the time of publication. Consult factory for up-to-date ordering information.
