CUSTOMER CONNECTION
SHELF 19", 1RU HOR,
3MDL,LVD,CXRF48-1.2kW
030-851-08
SHEET
NTS
REV
A
1 1
ITEM
QTY
REVISIONS
DESCRIPTION LTR APPD DATE DWN CHKD
6
CAN L
CAN COM
NOT CONNECTED
NOT CONNECTED
CAN H
FUNCTION
CAN IN RJ12 OFFSET
PIN
1
2
3
4
5
CAN +5V
TX+
RX+
NOT CONNECTED
NOT CONNECTED
TX-
FUNCTION
RX-
ETHERNET RJ45
PIN
1
2
3
4
5
6
7
8
NOT CONNECTED
NOT CONNECTED
1& &
.
& 1&
. 7 9 7
1& 12 & 12
. '
12
TX
RI
COM
CTS
RX
FUNCTION
DSR
CAUTION!
USE ONLY ALPHA DC MODEM
(SEE MANUAL FOR INSTRUCTIONS)
PIN
1
2
3
4
5
6
7
8
9
DTR
DCD
RTS
& & ) & & & ) ) ) ) ) ) & & & )
5 1
9 6
BATTERY HOT (-)
INSTRUCTIONS)
(SEE MANUAL FOR INSTALLATION
AC INPUTS (2 PLACES)
BATTERY RETURN (+)
H
CAN
OPEN
TERMINATION
TERMINATED
(DEFAULT)
DETAIL B
1 8
BATT
(+)
CXCM1 INTERFACE
(SEE MANUAL FOR INSTRUCTIONS)
DETAIL C
GMT FUSE DISTRIBUTION PANEL
MAX. 40 ADC
(SEE MANUAL FOR INSTRUCTIONS)
©
