7. Structure, éléments de réglage, éléments d’affichage et connecteurs
Description:
1.
Touches de programmation
2.
Contact anti-sabotage du couvercle
3.
Strap enfichable du contact anti-arrachement
4.
Bornier des sorties
5.
Bornier des entrées
6.
Strap enfichable de la résistance Pull-up + / Pull-down - au niveau des entrées
7.
Strap enfichable de l’INSTALLER MODE
8.
Emetteur de signaux
9.
Interrupteur DIP
10.
Prise Setup (non utilisée)
11.
Affichage à DEL
12.
Vis de fixation
SK1
1
2
4
3
5
11
7
6
8
9
10
SK1
12
x
