38
EXIT FAULT
This input should be triggered if the Secvest wireless indoor sounder is supposed to output the “Exit delay
time running with error” (zone open) sound.
Which wireless components respond when the inputs are triggered:
SET
STAT
E
PSET
STATE FLT STRB BELL TEST FIRE ENTRY EXIT EXIT
FAULT
Secvest
2WAY wireless
outdoor sounder X X X X
Secvest
wireless
indoor sounder X X X X X X X
Wireless remote
control
2WAY X X X
Wireless
operating
unit 2WAY X X X
Secvest Key
2WAY
wireless cylinder X X X
Possible output types on ABUS SC alarm centres for triggering the inputs:
Terxon SX/S MX/M MX/M Part
Parameter
081–083 Terxon LX/L
Function 31
SET STATE 26 active 1
In addition: 170 -> 00, 171 -> A
or
151–158 -> 30 active 1
In addition: 170 -> 00, 171 -> A System -> 009
PSET STATE 26 active 1
In addition: 170 -> 00, 171 -> B
or
151–158 -> 30 active 1
In addition: 170 -> 00, 171 -> B System-> 008 or
Partition -> 008
FLT 06 Ready
Externally inverted!
System-> 060 or
System-> 042 or
Partition -> 015
STRB 08 Flash follows
11 Active confirmation System-> 001 or
System -> 038
BELL 00 Siren System -> 000
TEST 05 Walk test System -> 013
FIRE 00 Siren
In addition: 174 -> 1
System -> 007
ENTRY 01 Input/output follows System-> 029 or
Partition -> 024
EXIT 01 Input/output follows System-> 030 or
Partition-> 025
EXIT FAULT System-> 032 or
Partition-> 027
Please refer to the installation guides for detailed descriptions of the switch outputs and the programming
codes of the alarm centres of the Terxon series.
