ABUS AZ4290 Terxon 2WAY Module User Manual
Page 136
136
7. Montering, indstillingselementer, visningselementer og tilslutninger
Beskrivelse:
1.
Programmeringstaster
2.
Dæksel –sabotagebeskyttelse
3.
Jumper til vægsabotagekontakten
4.
Klemmeblok udgange
5.
Klemmeblok indgange
6.
Jumper til Pull-up + / Pull-down - modstand på indgangene
7.
Jumper til INSTALLER MODE
8.
Signalgivere
9.
DIP-kontakt
10.
Setup-stik (ikke anvendt)
11.
LED-visning
12.
Fastgørelsesskrue
SK1
1
2
4
3
5
11
7
6
8
9
10
SK1
12
x
