ABUS AZ4290 Terxon 2WAY Module User Manual
Page 110
110
7. Opbouw, instelelementen, weergave-elementen en aansluitingen
Beschrijving:
1.
Programmeertoetsen
2.
Deksel – sabotageschakelaar
3.
Geleiderbrug voor de wandsabotageschakelaar
4.
Klemblok uitgangen
5.
Klemblok ingangen
6.
Geleiderbrug voor de pull-up + / pull-down - weerstand aan de ingangen
7.
Geleiderbrug voor de INSTALLER MODE
8.
Signaalgever
9.
DIP-schakelaar
10.
Setup-bus (niet gebruikt)
11.
LED-weergave
12.
Bevestigingsschroef
SK1
1
2
4
3
5
11
7
6
8
9
10
SK1
12
S
K
