Page 48
Serial Communication, cont’d
SGS 408 Switcher • Serial Communication
4-6
COMMAND
ASCII
RESPONSE
DESCRIPTION
Horizontal Size
Increment
X2
+:
X2
Hsz +
Increase output
X2
width one step
Decrement
X2
–:
X2
Hsz –
Decrease output
X2
width one step
Vertical Size
Increment
X2
+;
X2
Vsz +
Increase output
X2
height one step
Decrement
X2
–;
X2
Vsz –
Decrease output
X2
height one step
Horizontal Filter (Detail)
Specific value
X2
*
X6
D
X2
Dhz
X6
Select horizontal filter
X6
on output
X2
Increment
X2
+D
X2
Dhz
X6
Select next horizontal filter on output
X2
Decrement
X2
–D
X2
Dhz
X6
Select previous horizontal filter on output
X2
View
X2
D
X2
Dhz
X6
View current horizontal filter on output
X2
Vertical Filter (Detail)
Specific value
X2
*
X7
d
X2
Dvt
X7
Select vertical filter
X7
on output
X2
Increment
X2
+d
X2
Dvt
X7
Select next vertical filter on output
X2
Decrement
X2
–d
X2
Dvt
X7
Select previous vertical filter on output
X2
View
X2
d
X2
Dvt
X7
View current vertical filter on output
X2
Freeze Program & Preview
Enable freeze
X2
F
X2
Frz 1
Set
X2
freeze mode to On
Disable freeze
X2
f
X2
Frz 0
Set
X2
freeze mode to Off
Mute & Unmute
Mute
X2
B
X2
Mut 1
Set
X2
mute to On (set to black)
Unmute
X2
b
X2
Mut 0
Set
X2
mute to Off
Test Pattern
Select test pattern
X8
*
X9
J
Tst
X8
*
X9
Assign test pattern type
X8
to view
X9
or
X8
*
X9
j
Tst
X8
*
X9
Same as J above
View test pattern
J/j
Tst
X8
*
X9
View the current test pattern setting
Effect & Duration
Select effect+transition
X10
*
X11
#
Eff
X10
*
X11
Select effect
X10
with transition
X11
Select duration of effect
X12
#
Dur
X12
Select the length of time in which an effect occurs
View effect & duration
# Eff
X10
*
X11
•Dur
X12
View the effect transition and the effect duration
Executive Mode
Enable
X
Exe 1
Set executive mode to On
Disable
x
Exe 0
Set executive mode to Off
Program Lockout
Enable
K
Loc 1
Set program lockout to On
(see “Setting the
Disable
k
Loc 0
Set program lockout to Off
program lockout”
on page 3-7)
Output Rate
Set output rate
X13
*
X14
=
Rte
X13
*
X14
Select output resolution
X13
at vertical refresh rate
X14
View output rate
=
Rte
X13
*
X14
View the current output rate
Video Type
Set input video type
X1
*
X17
\
X1
Typ
X17
Select input
X1
video type
View input video type
X1
\
X1
Typ
X17
View input
X1
video type
Input Phase
Specific value
X2
*
X18
U/u
X2
Phs
X18
Set phase to
X18
for input on output
X2
.
View
X2
U/u
X2
Phs
X18
View the phase value for the current input on
output
X2
.
