Operation, cont’d
SGS 408 Switcher • Operation 3-4
5 Controls — Display the available controls. The configuration options are
available by pressing the Menu button. See “Configuring the SGS 408”
below.
6 Current duration — Displays the currently selected effect’s duration.
7 Current effect — Displays the effect and transition that are specified for the
active input. See “Applying other effects” on page 3-16 for details.
Configuring the SGS 408
To access all the configuration options, you must first enter the LCD menu
system. The default LCD menu appears on power up (figure 3-3).
Figure 3-3 — The default LCD menu
To display the first submenu of configuration options (figure 3-4), press the Menu
button.
Figure 3-4 — Displaying first submenu of options
To display the second submenu of configuration options (figure 3-5), press the
Next button.
Figure 3-5 — Displaying second submenu of options
Press the Exit button to return to the default menu (figure 3-3).
The LCD will always return to the default menu after 16 seconds of
inactivity in any submenu except when in Executive mode.
8 X X X . X X K H z X X . X X H z T i t l e
4 X X X . X X K H z X X . X X H z W i n d o w
1 2 8 0 X 1 0 2 4 @ 6 0 H z
T r u e ( D V I ) o n l y
3 . 4 S e c o n d s
M e n u C e n t e r S i z e F i l t e r L e v e l
I n p u t O u t O u t T e s t
N e x t C o n f i g R a t e S y n c P a t t e r n
E d i t P r o g
E x i t T i t l e L o c k L C D R e s e t
