Operation, cont’d – Extron Electronics SGS 408 User Guide User Manual
Page 30
Operation, cont’d
SGS 408 Switcher • Operation
3-12
E d i t
P r o g
E x i t
T i t l e
L o c k
L C D
R e s e t
Figure 3-23 — Performing a reset
2.
From the reset submenu, select either preview reset (PRE), program reset
(PRG), both preview and program reset (Both), system reset (System), or
escape (ESC) to return to the previous submenu (figure 3-24).
Figure 3-24 — Selecting the reset type
3.
If System is selected, the system reset submenu is displayed (figure 3-25).
Press the System button to reset the system, or press the ESC (escape) button
to cancel the system reset and return to the previous menu, or wait for the
16-second timeout to return to the default menu.
Figure 3-25 — Selecting the system reset
P R E
P R G
B o t h
S y s t e m
E S C
! ! C A U T I O N - R E S E T S A C T I V E ! !
S e l e c t W h i c h t o R e s e t
S y s t e m
E S C
! ! S Y S T E M R E S E T C O N F I R M ! !
P r e s s " S y s t e m " t o C o n f i r m
