MVP 104GX Programmer’s Guide
Programmer’s Guide, cont’d
COMMAND/RESPONSE TABLE
COMMAND
ASCII
RESPONSE
DESCRIPTION
Left Edge Size
Left edge size right
+H
Hph
Size left edge of input
image to the right
Left edge size left
–H
Hph
Size left edge of input
image to the left
Top Edge Size
Top edge size down
+/
Vph
Size top edge of input
image down
Top edge size up
–/
Vph
Size top edge of input
image up
Right Edge Size
Right edge size right
+:
Hsz
Size right edge of input
image to the right
Right edge size left
–:
Hsz
Size right edge of input
image to the left
Bottom Edge Size
Bottom edge size down
+;
Vsz
Size bottom edge of input
image down
Bottom edge size up
–;
Vsz
Size bottom edge input
image up
Top Blanking
Specific value
*
g
=T
Blt
g
Sets input
top blanking to
g
Increment up
+=T
Blt
g
Increment input
top blanking one step
Decrement down
–=T
Blt
g
Decrement input
top blanking one step
Bottom Blanking
Specific value
*
g
=B
Blb
g
Sets input
bottom blanking to
g
Increment up
+=B
Blb
g
Increment input
bottom blanking one step
Decrement down
–=B
Blb
g
Decrement input
bottom blanking one step
Left Blanking
Specific value
*
g
=L
Bll
g
Sets input
left blanking to
g
Increment up
+=L
Bll
g
Increment input
left blanking one step
Decrement down
–=L
Bll
g
Decrement input
left blanking one step
Right Blanking
Specific value
*
g
=R
Blr
g
Sets input
right blanking to
g
Increment up
+=R
Blr
g
Increment input
right blanking one step
Decrement down
–=R
Blr
g
Decrement input
right blanking one step
5-4
ASCII to HEX Conversion Table
Space
Figure 5-1 — ASCII-to-hexadecimal conversion table
