PowerCage 1600 Enclosure • Introduction
2
z
Modular, field-upgradeable, and hot-swappable design — The transmitter and
receiver boards, and primary and redundant power supplies, are hot-swappable,
allowing components to be added or replaced at any time without powering down the
system. This is useful for mission-critical applications that require continuous operation.
z
Efficient power management — Each PowerCage board can power down internal
components when no active signal is present, providing increased system efficiency.
z
Optional redundant power supply — For continuous, mission-critical applications
where power reliability is crucial, add a redundant power supply, part number 70-784-01.
z
Thermal management — The PowerCage enclosure provides channeled air flow to
each board for optimal cooling and reliable operation.
PowerCage FOX Fiber Optic Extender Boards
The fiber optic transmitter and receiver boards:
z
Are available in singlemode or multimode versions.
z
Support standard definition or high resolution video, HDMI, stereo audio, and RS-232
over a single fiber. They extend high resolution RGB, DVI-D, multi-rate SDI, standard
resolution component, S-video, or composite video extreme distances.
NOTE: Two fibers are needed when transmitting an HDCP signal.
z
Deliver pixel-for-pixel image quality for high resolution video. All digital, zero
compression transmission ensures image quality over long distances at high resolutions.
z
Provide alarm notification for fiber link loss and can be set up to trigger an external
control system for immediate notification when a fiber link has been lost.
z
PowerCage FOX DVI, DVI Plus, and VGA Fiber Optic Extenders are compatible with and
can be mixed and matched with FOXBOX and FOX 500 Series transmitters and receivers
for versatile system designs and configurations, including ultra-long distance DVI-to-
analog RGB and RGB-to-DVI conversion.
z
Include the following models:
z
z
PowerCage FOX VGA — Fiber Optic Extender for VGA, Audio, and RS-232
z
z
PowerCage FOX DVI, PowerCage FOX DVI Plus — Fiber Optic Extender for DVI,
Audio, and RS-232
z
z
PowerCage FOX 3G HD-SDI — Fiber Optic Extender for Multi-Rate SDI
z
z
PowerCage FOX AV — Fiber Optic Extender for Video, Audio, and RS-232
z
z
PowerCage FOX HDMI — Fiber Optic Extender for HDMI, Audio, and RS-232
PowerCage MTP Twisted Pair Boards
The twisted pair transmitter and receiver boards:
z
Support standard definition or high resolution video, and audio or RS-232 over a single
CAT 5/5e/6 (shielded or unshielded) cable. They transmit and receive high resolution RGBHV,
RGBS, RGsB, RsGsBs, component video, S-video, and composite video long distances.
z
Include the following models:
z
z
PowerCage MTP T 15HD RSA — MTP Twisted Pair Transmitter for VGA and Audio
or RS-232
z
z
PowerCage MTP R 15HD RSA SEQ — MTP Twisted Pair Receiver for VGA and
Audio or RS-232 with Skew Equalization
z
z
PowerCage MTP T AV — MTP Twisted Pair Transmitter for Composite or S-video
and Audio
z
z
PowerCage MTP R AV — MTP Twisted Pair Receiver for Composite or S-video and Audio
