PowerCage 1600 Enclosure • Specifications and Part Numbers 15
Video — PowerCage FOX Tx/Rx AV
NOTE: For PowerCage FOX AV boards, the analog video input signal is digitized pixel for pixel in the transmitter,
sent digitally through the fiber cable, and converted back to analog video in the receiver.
Gain ............................................... Unity
Standards
Input ....................................... NTSC 3.58, NTSC 4.43, PAL, SECAM, autodetected
Output .................................... NTSC 3.58, PAL (follows vertical rate)
Decoder type .................................. Adaptive 2D, digital comb filter
Video input — PowerCage FOX Tx AV
Number/signal type ........................ 1 component (Y, R-Y, B-Y), S-video, composite video
Connectors .................................... 1 x 3 female BNC or 1 female 4-pin mini DIN for S-video
Nominal levels ................................ 1.0 Vp-p for Y of component video and S-video, and for composite video
0.7 Vp-p for R-Y, B-Y of component video
0.3 Vp-p for C of S-video
Minimum/maximum levels .............. Analog: 0.3 V to 1.5 Vp-p with no offset
Impedance ..................................... 75 ohms
Return loss ..................................... -30 dB for Y/VID, B-Y/C, R-Y @ 5 MHz
Input coupling ................................ AC
Video output — PowerCage FOX Rx AV
Number/signal type ........................ 1 component (Y, R-Y, B-Y) video, S-video, composite video
Connectors .................................... 1 x 3 female BNC or 1 female 4-pin mini DIN for S-video
Nominal levels ................................ 1.0 Vp-p for Y of component video and S-video, and for composite video
0.7 Vp-p for R-Y, B-Y of component video
0.3 Vp-p for C of S-video
Minimum/maximum levels .............. 0.3 V to 1.5 Vp-p
Impedance ..................................... 75 ohms
Return loss ..................................... <-40 dB @ 5 MHz
DC offset ....................................... +350 mV, maximum, with input at 0 offset
Video delay .................................... 1-2 frames
Video — PowerCage FOX Tx/Rx HDMI
NOTE: Appropriate DMI to DVI-D cables or adapters are required for DVI signal input and output.
Maximum data rate ........................ 4.95 Gbps (1.65 Gbps per color)
Maximum pixel clock ...................... 165 MHz
Resolution range ............................ Up to 1920x1200 or 1080p @ 60 Hz, 8-bit color
Formats .......................................... RGB, YCbCr, xvYCC digital video
Standards ....................................... DVI 1.0, HDMI, HDCP 1.1, CEA-861E
Video input — PowerCage FOX Tx HDMI
Number/signal type ........................ 1 single link HDMI
Connectors .................................... 1 female 19-pin HDMI type A
Video output — PowerCage FOX Rx HDMI
Number/signal type ........................ 1 single link HDMI
Connectors .................................... 1 female 19-pin HDMI type A
Video — PowerCage MTP T 15HD RSA, PowerCage MTP R 15HD RSA SEQ
Gain ............................................... Unity
Number/signal type ........................ 1 set of proprietary analog signals
Connector ...................................... 1 female RJ-45
