PowerCage 1600 Enclosure • Specifications and Part Numbers 17
Video output — PowerCage MTP R AV
Number/signal type ........................ 1 S-video or composite video
Connectors .................................... 2 female BNC
Nominal level ................................. 1 V p-p for Y of S-video and for composite video
0.3 V p-p for C of S-video
Minimum/maximum level ............... 0.3 V to 1.5 Vp-p
Impedance ..................................... 75 ohms
Return loss ..................................... <-35 dB @ 5 MHz
DC offset ....................................... ±20 mV with input at 0 offset
Sync — PowerCage MTP T AV, PowerCage MTP R AV
Standards ....................................... NTSC 3.58, NTSC 4.43, PAL, SECAM
Audio — PowerCage FOX Tx/Rx VGA, PowerCage FOX Tx DVI,
PowerCage FOX Tx/Rx DVI Plus, PowerCage FOX Tx/Rx AV, PowerCage FOX Tx/Rx HDMI
NOTE: In PowerCage FOX boards, the analog audio signal(s) is (are) digitized in the transmitter, sent through the
fiber cable, and converted back to analog audio in the receiver.
Gain
Range ...................................... Adjustable, -18 dB to +10 dB
Default
PowerCage FOX Tx/Rx HDMI Unbalanced output: 0 dB
All other boards ................. Unbalanced output: -6 dB; balanced output: 0 dB
Frequency response ........................ 20 Hz to 20 kHz, ±0.5 dB
THD + Noise
VGA, DVI, and HDMI boards .... 0.10% @ 1 kHz at nominal level
AV boards ................................ 0.15% @ 1 kHz at nominal level
S/N ................................................. >80 dB at maximum output (unweighted)
CMRR ............................................ 65 dB @ 20 Hz to 20 kHz
Audio bits per sample ..................... 18 bits per channel, 2 channels (L, R)
Sampling rate ................................. 48 kHz
Audio input — PowerCage FOX Tx VGA, PowerCage FOX Tx DVI,
PowerCage FOX Tx DVI Plus
Number/signal type ........................ 1 stereo, balanced/unbalanced or
2 mono, balanced/unbalanced
Connector ...................................... (1) 3.5 mm captive screw connector, 5 pole
Impedance ..................................... 18k ohms unbalanced, DC coupled
Nominal level ................................. +4 dBu (1.23 Vrms), -10 dBV (316 mVrms)
Maximum level ............................... +8.9 dBV, unbalanced at 1% THD+N
NOTE: 0 dBu = 0.775 Vrms, 0 dBV = 1 Vrms, 0 dBV ≈ 2 dBu
Audio input — PowerCage FOX Tx AV
Number/signal type ........................ 1 stereo, balanced/unbalanced or
2 mono, balanced/unbalanced
Connector ...................................... (1) 3.5 mm captive screw connector, 5 pole
Impedance ..................................... >10k ohms unbalanced, >20k ohms balanced, DC coupled
Nominal levels ................................ +4 dBu (1.23 Vrms), -10 dBV (316 mVrms)
Maximum level ............................... +17 dBV, unbalanced at 1% THD+N
NOTE: 0 dBu = 0.775 Vrms, 0 dBV = 1 Vrms, 0 dBV ≈ 2 dBu
