PowerCage 1600 Enclosure • Specifications and Part Numbers 16
Video input — PowerCage MTP T 15HD RSA
Number/signal type ........................ 1 analog RGBHV, RGBS, RGsB, RsGsBs, component video (YUVi or YUVp/HDTV),
S-video, or composite video
Connector ...................................... 1 female 15-pin HD
Nominal levels ................................ 1 Vp-p for Y of component video and S-video, and for composite video
0.7 Vp-p for RGB and for R-Y and B-Y of component video
0.3 Vp-p for C of S-video
Minimum/maximum levels .............. 0.3 V to 1.45 Vp-p
Impedance ..................................... 75 ohms
Horizontal frequency ...................... 15 kHz to 130 kHz
Vertical frequency ........................... 30 Hz to 150 Hz
Return loss ..................................... <-30 dB @ 5 MHz
DC offset (max. allowable) ............. 250 mV
Video output — PowerCage MTP R 15HD RSA SEQ
Number/signal type ........................ 1 analog VGA-UXGA RGBHV, RGBS, RGsB, RsGsBs, component video (YUVi or
YUVp/HDTV), S-video, or composite video
Connector ...................................... 1 female 15-pin HD
Nominal levels ................................ 1 Vp-p for Y of component video and S-video, and for composite video
0.7 Vp-p for RGB and for R-Y and B-Y of component video
0.3 Vp-p for C of S-video
Minimum/maximum levels .............. 0.3 V to 1.45 Vp-p
Impedance ..................................... 75 ohms
Return loss ..................................... <-30 dB @ 5 MHz
DC offset ....................................... <±35 mV with input at 0 offset
Skew compensation ....................... 62 ns
Maximum resolution ...................... Up to 1920x1200 or 2048x1080 or 1080p at 300'
Up to 1024x768 at 600'
NOTE: Refer to the user guide for the maximum distances recommended for specific resolutions.
Sync — PowerCage MTP T 15HD RSA, PowerCage MTP R 15HD RSA SEQ
Input/output type ........................... RGBHV, RGBS, RGsB, RsGsBs
Standards ....................................... NTSC 3.58, NTSC 4.43, PAL, SECAM
Input level (transmitter) .................. 3.5 V to 5.5 Vp-p, unterminated
Output level (receiver) .................... 4.0 V to 5.0 Vp-p, unterminated
Input impedance (transmitter) ........ 573 ohms ±5%
Output impedance (receiver) .......... 110 ohms
Polarity
Transmitter .............................. Positive or negative (follows input polarity)
Receiver ................................... Positive or negative (switch-selectable)
Video — PowerCage MTP T AV, PowerCage MTP R AV
Gain ............................................... Unity
Differential phase error ................... <1.0° at 3.58 MHz and 4.43 MHz
Differential gain error ..................... <1.0% at 3.58 MHz and 4.43 MHz
Video input — PowerCage MTP T AV
Number/signal type ........................ 1 S-video or composite video
Connectors .................................... 2 female BNC
Nominal level ................................. 1 Vp-p for Y of S-video and for composite video
0.3 Vp-p for C of S-video
Minimum/maximum levels .............. 0.3 V to 1.5 Vp-p with no offset
Impedance ..................................... 75 ohms
Return loss ..................................... <-30 dB, DC @ 10 MHz
DC offset (max. allowable) ............. 250 mV
